An external high speed folding door for loading bays, built to withstand UK weather without slowing down goods-in.
check
External Folding Design
check
Withstands UK Weather
check
Ideal for Loading Bays
FOLD-UP is built for exposed external openings — loading bays and large doorways where wind, rain and general UK weather rule out a standard rapid door.
Rapid opening and closing keeps goods-in moving through loading bays without long waits at the door, even on a busy site with constant vehicle and forklift traffic.
Where wind load is a genuine structural concern, FOLD-UP’s folding design and weatherproofing are built to hold up on sites where a roll door alone wouldn’t be enough.
01
blu. Technology
Blu, the GS Doors' smart control technology, for real-time diagnostics, remote monitoring and support — all from your phone.
02
Best For: Loading Bays
Exposed external loading bays and large doorways that need to stand up to UK wind and rain.
03
Installed & Guaranteed
Every Fold Up is installed by our own specialist technicians, with maintenance covered under a 12-month warranty and spare parts available UK-wide.
FOLD-UP®
Drive unit
Side-mounted / Front-mounted
Header beam
Self-supporting with easyfix system / Non-self-supporting
Side frames
Profile housing the electrical system
Lifting straps
For lifting the curtain
Installation
Indoor / Outdoor
Maximum clear opening
Width 8000 mm · Height 7000 mm
Wind resistance
Class 2 up to 8000 × 7000 mm
Class 3 – Class 4 on a project basis
Opening speed
Up to 1.5 m/s
Closing speed
0.5 m/s
Power supply
400 V three-phase
Controls
Start, Stop, Partial opening and Close commands built into the BLU Box control panel
Curtain
PVC fabric with horizontal metal tubes
Safety devices
Self-excluding IP67 safety barrier
Our technical sales team will kick things off with a consultation to understand your specific needs.
Next, we'll conduct an on-site assessment to understand the application, gather measurements and identify any potential challenges.
Following the survey, we'll allocate one of our experienced, fully trained partners to supply and install the door in your location.
If you need help with your door following the install, our technical support team is just a phone call away.
Download the GS Doors catalogue for complete specifications, dimensions and technical drawings across the full range.
AUTO-FULL®
High Speed Roll Door for Industrial Use
AUTO-FRIGO®
High Speed Door for Cold Storage
AUTO-FREEZER®
High Speed Door for Freezer Rooms
DUAL-FREEZER®
Maximum-Insulation Door for Sub-Zero Storage
DUAL-AIR®
Extra-Large Folding Door with Wind Protection
AUTO-FULL AC®
High Speed Roll Door with Air Curtain
AUTO-FRIGO AC®
Cold Storage Door with Air Curtain
AUTO-FREEZER AC
Freezer Door with Air Curtain
AUTO-PHARMA®
High Speed Door for Cleanroom & Pharmaceutical Use
AUTO-MACHINE®
Compact Door for Machine Guarding
Drag
Tell us about your opening — dimensions, sector, timeline — and a GS Doors specialist will get back to you with a tailored recommendation and quote for FOLD-UP®.
FOLD-UP is built for standard external openings; DUAL-AIR is designed for extra-large folding doors where reinforced wind protection is the priority.
Yes — FOLD-UP’s folding design and weatherproofing are built to hold up on sites where a roll door alone wouldn’t be enough.
Yes — installation is carried out by our specialist technicians, with maintenance covered under a 12-month warranty.
